Reliasoft Weibull Crack

Weibull probability plot: We generated 100 Weibull random variables using (T ) = 1000, ( gamma ) = 1.5 and ( alpha ) = 5000. To see how well these random Weibull data points are actually fit by a Weibull distribution, we generated the probability plot shown below. Note the log scale used is base 10. The requirements should include a clear definition of product failure. The failure can be a complete failure or degradation of the product. For example: part completely breaks, part cracks, crack length exceeds 10 mm, part starts shaking, etc. The definition is incorporated into tests and should be used consistently throughout the analysis. Weibull 6 MT is a special industry-specific version of ReliaSoft's Weibull life data analysis software, designed to meet the needs of the machine tool supplier community. Weibull MT is designed to speed up and simplify the extremely. PCWin Note: ReliaSoft Weibull MT 6.0 download version indexed from servers all over the world. ReliaSoft software from HBM Prenscia empowers reliability, quality and maintainability engineers to transform data into decisions. These innovative tools provide a powerful range of reliability and maintainability software solutions to facilitate a comprehensive set of reliability engineering modeling and analysis techniques, such as life data analysis, accelerated life testing, system.

Posted by admin

Published online 2016 Jun 27. doi: 10.3390/ma9070521

Jordi Faraudo, Academic Editor

Author informationArticle notesCopyright and License informationDisclaimer

This article has been cited by other articles in PMC.

Associated Data

Supplementary Materials

Abstract

The typical experimental procedure for testing stress corrosion cracking initiation involves an interval-censored reliability test. Based on these test results, the parameters of a Weibull distribution, which is a widely accepted crack initiation model, can be estimated using maximum likelihood estimation or median rank regression. However, it is difficult to determine the appropriate number of test specimens and censoring intervals required to obtain sufficiently accurate Weibull estimators. In this study, we compare maximum likelihood estimation and median rank regression using a Monte Carlo simulation to examine the effects of the total number of specimens, test duration, censoring interval, and shape parameters of the true Weibull distribution on the estimator uncertainty. Finally, we provide the quantitative uncertainties of both Weibull estimators, compare them with the true Weibull parameters, and suggest proper experimental conditions for developing a probabilistic crack initiation model through crack initiation tests.

Keywords: crack initiation test, estimation uncertainty, Monte Carlo simulation, Weibull distribution

1. Introduction

Stress corrosion cracking (SCC) is one of the main material-related issues that occur in the operation of nuclear reactors [1,2,3]. Particularly, in pressurized water reactors, the occurrence of SCC at a reactor’s pressure boundary can cause a loss-of-coolant accident. Therefore, many researchers have endeavored to predict SCC initiation time for a given component. However, accurately predicting SCC initiation is difficult because the mechanism is quite complex and not yet clearly understood; instead, empirical SCC initiation models are generally considered [4,5,6].

However, most SCC experiments show significant variation in cracking time, even though all specimens are tested in the same experimental conditions (e.g., temperature and stress level). Therefore, the Weibull distribution [7], which considers the effect of time-dependent material degradation, is widely accepted as a probabilistic model for SCC initiation time [6,8,9]. Probabilistic models cannot offer an exact cracking time but can offer a cracking probability as a function of time for a given set of conditions. In this case, SCC initiation testing is required to determine the cracking probability function (i.e., the unreliability function).

The typical experimental procedure of an SCC initiation test involves an interval-censored reliability test. That is, stressed specimens are exposed to a corrosive environment and censored at scheduled periods. The results of these tests can be used to estimate the parameters of a Weibull distribution, using either maximum likelihood estimation (MLE) or median rank regression (MRR) [10].

Both estimation methods for Weibull parameters are anticipated to be more accurate with more test specimens and narrower censoring intervals. However, we do not yet know the optimal number of test specimens and censoring intervals required to estimate a sufficiently accurate Weibull distribution. In this study, we use Monte Carlo simulation to compare MLE and MRR estimators and quantify the effects of specimen number, test duration, and censoring interval on the uncertainty of the estimated Weibull parameters.

2. Weibull Estimation

2.1. Weibull Distribution

The cumulative distribution function (CDF) of a two-parameter Weibull distribution is frequently used as a cracking probability function, and is given by [10]:

where t is time, β is the shape parameter, and η is the scale parameter of the Weibull distribution.

If β < 1, the cracking rate, or hazard function, decreases with time. If β > 1, the cracking rate increases monotonically. This indicates time-dependent material degradation, or aging effects. If β = 1, the Weibull distribution becomes equivalent to an exponential distribution and the cracking rate is not influenced by time. The scale parameter η is also called characteristic time, which is the quantile at which the CDF of the Weibull distribution reaches approximately 0.632.

2.2. Median Rank Regression

MRR is a method that can derive a cracking probability function from the result of a crack initiation test. It is reasonable to assume that all specimens are tested independently; that is, the status of one specimen does not affect the cracking probability of the other specimens.

Let N be the total number of specimens and j be the number of cracked specimens. Then, the distribution of j at a certain time follows a binomial distribution. The CDF of the binomial distribution can be expressed as follows [11]:

\begin{matrix} {CDF}_{Bin} (j; N, F (t)) & = \sum_{i = 0}^{j} (\begin{matrix} N \\ i \end{matrix}) {[F (t)]}^{i} {[1 - F (t)]}^{N - i} \\ = (N - j) (\begin{matrix} N \\ j \end{matrix}) \int_{0}^{1 - F (t)} t^{N - j - 1} {(1 - t)}^{j} d t \\ = I_{1 - F (t)} (N - j, j + 1) \end{matrix}

where F(t) is the cracking probability function and I is the regularized incomplete beta function. When CDF_Bin is set to 0.5, the value of F(t) at a certain time can be calculated, and is called the median rank. If the total number of specimens is very large, the value of the median rank is close to the cracked fraction j/N.

Benard and Bos-Levenbach [12] suggested a simple approximation for non-statisticians to easily calculate the median rank:

where F_Med(t) is the cracking probability function calculated using median rank. Figure 1 shows that the exact median rank values are very close to their approximations. Therefore, in this study, we use the approximation, defined in Equation (3), to improve calculation speed.

Comparison of exact median rank values (blue line) and their approximations (red squares) when: (a) N = 5; and (b) N = 10.

If the test is not censored continuously (i.e., if it is an interval-censored test), the resulting F_Med(t) must be treated as a set of unreliability points and not as a function. With this median rank point set, it is possible to estimate the Weibull distribution, which is the model of SCC initiation, through regression [10,13]. Figure 2 is an example of Weibull estimation using MRR that uses the test data in Table 1. The red dots show the median rank points, F_MRR(t) is the estimated Weibull CDF by regression with the median rank points, and ${\hat{β}}_{M R R}$ and ${\hat{η}}_{M R R}$ are the Weibull shape and scale parameters, respectively, estimated by MRR.

Example of Weibull estimation by MRR with the test data from Table 1.

Table 1

Example of a cracking initiation test result with six specimens.

Censoring Time (h)	Cracked Fraction	Median Rank
100	0/6	0
250	0/6	0
500	1/6	0.1091
700	1/6	0.1091
900	3/6	0.4214
1200	6/6	0.8909

A widely used Weibull regression technique employs the linearization of the Weibull distribution, which is as follows:

(4)

However, this Weibull estimation method encounters limitations. First, it cannot handle the case in which there are zero cracking points, which returns a negative infinity value in the linearized form. Second, the Weibull distribution is nonsymmetrical and the error in the rank probability estimation is not random in nature [14]. Weights in the MRR linear function are based on the incorrect assumption of uncorrelated, equal variance residuals [15]. Therefore, we used a nonlinear curve-fitting function, lsqcurvefit, provided by MATLAB, which is based on the least squares method.

2.3. Maximum Likelihood Estimation

The MLE method estimates the parameters of the Weibull distribution directly by using the likelihood function, instead of the cracking probability at each censoring point. The likelihood function for the interval-censored case is given by [13]:

L (β, η) = \prod_{i = 1}^{S} [1 - F (s_{i}; β, η)] \cdot \prod_{j = 1}^{C} [F (c_{j_{U}}; β, η) - F (c_{j_{L}}; β, η)]

where S is the number of suspended specimens, s_i is the last censoring time of i_th suspended specimen, C is the number of interval-censored cracked specimens, and c_{j_U} and c_{j_L} are the upper and lower bound times, respectively, of the censoring interval for the j_th cracking. The sum of S and C is equal to the total number of specimens N.

The use of log-likelihood is convenient to determine the Weibull parameters that maximize the likelihood function (i.e., $\arg max_{(β, η)} L (β, η)$ ). The log-likelihood function is as follows:

\begin{matrix} Λ (β, η) & = \ln L (β, η) \\ = \sum_{i = 1}^{S} \ln [1 - F (s_{i}; β, η)] + \sum_{j = 1}^{C} \ln [F (c_{j_{U}}; β, η) - F (c_{j_{L}}; β, η)] \end{matrix}

The maximum likelihood point is obtained where both partial derivatives of Λ(β, η) reach zero. Therefore, the maximum likelihood point is given by:

Substituting Equations (1) and (6) into Equation (7), we can obtain the final simultaneous equation:

{\begin{matrix} \sum_{i = 1}^{s} [- {(\frac{s_{i}}{η})}^{β} \ln (\frac{s_{i}}{η})] + \sum_{j = 1}^{c} [\frac{- {(\frac{c_{j L}}{η})}^{β} \ln (\frac{c_{j L}}{η}) \exp [- {(\frac{c_{j L}}{η})}^{β}] + {(\frac{c_{j U}}{η})}^{β} \ln (\frac{c_{j U}}{η}) \exp [- {(\frac{c_{j U}}{η})}^{β}]}{\exp [- {(\frac{c_{j L}}{η})}^{β}] - \exp [- {(\frac{c_{j U}}{η})}^{β}]}] = 0 \\ \sum_{i = 1}^{s} [(\frac{β}{η}) {(\frac{s_{i}}{η})}^{β}] + \sum_{j = 1}^{c} [(\frac{β}{η}) \frac{{(\frac{c_{j L}}{η})}^{β} \exp [- {(\frac{c_{j L}}{η})}^{β}] - {(\frac{c_{j U}}{η})}^{β} \exp [- {(\frac{c_{j U}}{η})}^{β}]}{\exp [- {(\frac{c_{j L}}{η})}^{β}] - \exp [- {(\frac{c_{j U}}{η})}^{β}]}] = 0 \end{matrix}

The derivation of Equation (8) is available in the Supplementary Materials. It would be extremely difficult to determine a general analytical solution for Equation (8); therefore, we used a numerical approach. In this case, MATLAB offers the numerical nonlinear simultaneous equation function fsolve.

3. Monte Carlo Simulation

The goals of MRR and MLE are the same: the estimation of Weibull parameters. However, the resulting estimators are slightly different, even though they were both deduced from the same test result. Figure 3 shows the different Weibull curves estimated from the same test data, found in Table 1. It is intriguing to know which estimation method generates more precise estimators. A Weibull distribution with precise estimators could better describe inherent SCC initiation behavior.

Comparison of different Weibull curves estimated by MRR or MLE from the test data in Table 1. The blue line is the Weibull curve estimated by MRR and the red line is that by MLE. The black squares are the median rank points.

Theoretically, it is possible to calculate the estimation confidence for data containing the exact cracking time only; that is, when cracking is continuously monitored using a direct current potential drop technique. However, an MLE theory to set the estimation confidence for interval-censored data is not yet available [10]. Therefore, Monte Carlo simulation [16] could be used to quantitatively evaluate estimator uncertainties of MLE and MRR. The experimental factors considered in the simulation study are as follows.

True Weibull parameters: It is assumed that the inherent cracking probability is Weibull-distributed. If the standardized estimation errors were affected by the value of the true scale parameter (η_true), only changing the time unit (e.g., hours to seconds) could affect standardized estimation errors. It is a contradiction. In fact, a scale parameter is just a scale factor. Therefore, standardized estimation errors are not affected by the value of η_true [15]. Without loss of generality, η_true can be fixed at 100, whereas the value of the true Weibull shape parameter (β_true) could affect the standardized estimation errors. To examine the degree of aging effects, several values of β_true (2, 3, and 4) are examined. In earlier studies, the values of the Weibull shape parameter for crack initiation time range from 2 to ~4 [6,17,18,19].
The number of specimens: The SCC initiation test for nuclear reactor materials requires a corrosive environment at high temperatures and pressures. Thus, simultaneously testing a large number of specimens is difficult. Therefore, the base number of test specimens is set at 10. To evaluate the effect of the number of specimens, additional cases were studied (see Table 2).
Table 2
Experimental conditions for the Monte Carlo simulation.
True Weibull Parameter Number of Specimens Test Duration (% of η_true) Censoring Interval (% of η_true)
η_true (Dimensionless Time) β_true
100 2 5 80 5
3 7 100 10
4 10 * 120 * 15
15 140 20 *
20 160 30
30 180 40
50 200 60
Test duration: When planning the SCC test, cracking will not necessarily occur for every specimen within the available testing time. Thus, the test duration is also a factor affecting the uncertainty of Weibull estimators. For convenience, the baseline test duration is set at 120% of η_true. Additional test duration cases are shown in Table 2.
Censoring interval: A shorter censoring interval may be better for developing an accurate SCC initiation model. However, frequent censoring would be inconvenient for the experimenters. Therefore, the baseline censoring interval is set at 20% of η_true. Other examined interval cases are shown in Table 2. Although time-dependent censoring intervals are more general for real cracking tests, it is assumed that censoring intervals do not vary with time. If we consider time-dependent censoring intervals, there are too many possible combinations of experimental conditions to perform a simulation study.

True Weibull Parameter	Number of Specimens	Test Duration (% of η_true)	Censoring Interval (% of η_true)
100	2	5	80	5
3	7	100	10
4	10 *	120 *	15
15	140	20 *
20	160	30
30	180	40
50	200	60

Figure 4 shows examples of the simulation experiments with different combinations of conditions. Weibull_True represents the pre-assumed true cracking probability, which follows a Weibull distribution. Median_Rank is the set of cumulative cracking point probabilities resulting from the randomly simulated cracking experiments and is calculated by the median rank method. Weibull_MLE and Weibull_MRR are the estimated Weibull distributions obtained from simulation experiments using MLE and MRR, respectively.

Two examples of simulation experiments with relatively (a) poor test condition; and (b) ideal test condition.

Figure 4a is an example of a simulation in which the number of specimens is relatively small, the censoring interval is wide, and the test duration is short. In this case, the estimated Weibull curves, Weibull_MLE and Weibull_MRR, are quite different from the true cracking probability curve, Weibull_True. Figure 4b shows another example of the simulation, in which the number of specimens is relatively large, the censoring interval is narrow, and the test duration is long. In this simulation, the estimated Weibull curves approximate the true Weibull curve, following our intuition. The detailed experimental conditions applied in Figure 4 are described in Table 3.

Table 3

Combinations of experimental factors applied to examples in Figure 4.

Factors	Figure 4a	Figure 4b
η_true (dimensionless time)	100	100
β_true	2	4
The number of specimen	10	50
Test duration (% of η_true)	120	200
Censoring interval (% of η_true)	40	5

By combining the considered experimental conditions, a total of 441 simulation cases were studied. Each case was simulated 20,000 times.

We think that it is important to represent the degree of bias and degree of dispersion of estimators respectively in every specific experimental condition. For the experimenters who want to develop a cracking prediction model, both the degree of bias and degree of dispersion of estimators are necessary to guess their model uncertainty. For the same reason, the estimation uncertainties of β and η are respectively represented.

The 5th, 50th, and 95th percentiles of the Weibull estimators were derived from each simulation case. Further, these estimators were converted to the standard error, which is defined as follows:

where $\hat{β}$ and $\hat{η}$ are the Weibull parameters estimated by MRR or MLE. To quantify the Weibull estimator deviations, we utilized a standardized length of 90% confidence interval, defined as follows:

{SLCI}_{90 %} (\hat{β}) = SE ({\hat{β}}_{95 %}) - SE ({\hat{β}}_{5 %}); {SLCI}_{90 %} (\hat{η}) = SE ({\hat{η}}_{95 %}) - SE ({\hat{η}}_{5 %}) .

The true Weibull parameters (β_true, η_true) are input as initial values of numerical solvers (i.e., the fsolve and lsqcurvefit functions in MATLAB). If a given combination of experimental conditions is too poor (e.g., cases with a small specimen number and wide censoring interval), it is possible to fail to find estimators with this numerical approach; in these cases, we exclude the failed estimators.

4. Results and Discussion

4.1. Fixed Test Duration

We fixed the test duration at 120% of η_true, the baseline case for test duration, to examine both the effects of the number of specimens and censoring interval.

As a special case, Figure 5 shows the effect of the number of specimens on estimation uncertainties when the censoring interval is fixed to 20% of η_true. When the number of specimens is large, there is a high probability of precise and accurate estimation with both MRR and MLE. For estimating the shape parameter β, MRR and MLE provide similar estimation uncertainty levels (see Figure 5a–c). It is likely that the shape parameters are overestimated with high probability when the number of specimens is less than 30 (i.e., ${SE}_{50 %} (\hat{β}) > 0$ ). For the scale parameter η estimation, smaller deviation levels are observed in the estimation of scale parameter η for all ranges of specimen number as compared with those of the β estimators, especially at the high β_true (see Figure 5d–f). Notably, the scale parameters estimated through MLE have a very slight bias in all ranges of specimen number (i.e., ${SE}_{50 %} ({\hat{η}}_{MLE}) \approx 0$ ).

Effect of specimens number on $SE (\hat{β})$ at: (a) β_true = 2; (b) β_true = 3; and (c) β_true = 4; and on $SE (\hat{η})$ at: (d) β_true = 2; (e) β_true = 3; and (f) β_true = 4 (censoring interval: 20% of η_true; test duration: 120% of η_true).

From these data, it is possible to calculate the confidence interval and bias of the estimators when real cracking test conditions are given. For example, if the test duration is 120% of η_true and the censoring interval is 20% of η_true, the probability of obtaining $0.853 < \frac{{\hat{η}}_{MLE}}{η_{t r u e}} < 1.151$ is approximately 90% and $\frac{{\hat{η}}_{MLE, 50 %}}{η_{t r u e}} ≅ 1$ with only 10 specimens when β_true = 4 for the testing material (see Figure 5f).

Mar 13, 2018 - Newer iterations of the software replace CAMREC files with TREC files in. File without Camtasia, using one of these free video converter tools. 5k player for windows 10. Sep 23, 2017 - But they wouldn't open in windows media player. Can somebody help me what should i do for how to play camrec files in windows media.

Figure 6 shows the convergence ratio distributions of MLE numerical estimation. The convergence ratio is defined as follows:

Convergence Ratio = \frac{Number of converged estimations by numerical solver}{Number of total simulation (= 20,000)}

Convergence ratio distributions of MLE numerical estimation at: (a) β_true = 2; (b) β_true = 3; and (c) β_true = 4 when test duration is 120% of η_true.

The convergence ratio decreased when the number of specimens was small and the censoring interval was wide. This trend was enlarged when the value of β_true increased. If the convergence ratio were too low, there would be a filtering effect caused by the disregard of outlier estimators. That is, for low convergence ratio region, output estimators were not purely random. It is recommended to be careful when analyzing the results in this region.

Although it is known that MLE convergence ratios might be improved by restricting β > 1 [20], we did not use this algorithm in this study. It will be considered in later research. For MRR estimation, the convergence ratios were mostly close to unity in all simulation cases.

Figure 7 shows the distributions of ${SE}_{50 %} (\hat{β})$ by MLE or MRR. These results indicate a bias in Weibull shape parameter estimation. It is likely that when the number of specimens is relatively small, β_true tends to be overestimated, as in Figure 5. However, this trend did not occur when MLE was used and the censoring interval was relatively wide. Furthermore, if the value of β_true was relatively large, underestimation occurred in wide censoring interval regions of MLE estimators (see Figure 7c).

Distributions of ${SE}_{50 %} ({\hat{β}}_{M L E})$ at: (a) β_true = 2; (b) β_true = 3; and (c) β_true = 4; and ${SE}_{50 %} ({\hat{β}}_{M R R})$ at: (d) β_true = 2; (e) β_true = 3; and (f) β_true = 4 (test duration: 120% of η_true).

Figure 8 shows the distributions of ${SE}_{50 %} (\hat{η})$ by MLE or MRR. These results indicate bias in Weibull scale parameter estimation. It is interesting that when MLE was used, very little bias was observed in all simulation cases. For MRR, a tendency toward overestimation (i.e., ${SE}_{50 %} (\hat{η}) > 0$ ) occurred when the number of specimens was relatively small. This tendency was slightly amplified when β_true was relatively small.

Distributions of ${SE}_{50 %} ({\hat{η}}_{M L E})$ at: (a) β_true = 2; (b) β_true = 3; and (c) β_true = 4; and ${SE}_{50 %} ({\hat{η}}_{M R R})$ at: (d) β_true = 2; (e) β_true = 3; and (f) β_true = 4 (test duration: 120% of η_true).

Figure 9 shows the distributions of ${SLCI}_{90 %} (\hat{β})$ by MLE or MRR. These results illustrate the variance in Weibull shape parameter estimators. As anticipated, the variance in $\hat{β}$ was large when the number of specimens was relatively small and the censoring interval was wide. It is likely that there are critical lines after which estimators whose variances are too large are produced. Near the critical lines, the gradients of ${SLCI}_{90 %} (\hat{β})$ were very high. Experimenters who want to develop cracking prediction models with a cracking test should avoid this region.

Distributions of ${SLCI}_{90 %} ({\hat{β}}_{M L E})$ at: (a) β_true = 2; (b) β_true = 3; and (c) β_true = 4; and ${SLCI}_{90 %} ({\hat{β}}_{M R R})$ at: (d) β_true = 2; (e) β_true = 3; and (f) β_true = 4 (test duration: 120% of η_true).

Figure 10 shows the distributions of ${SLCI}_{90 %} (\hat{η})$ by MLE and MRR. These results show the variance in Weibull scale parameter estimators. The overall values of the ${SLCI}_{90 %} (\hat{η})$ distributions were much lower than those of the ${SLCI}_{90 %} (\hat{β})$ distributions, especially for the case of high β_true values. Interestingly, shortening the censoring interval slightly affects the reduction of estimator deviations as compared to the case of ${SLCI}_{90 %} (\hat{β})$ , and there is no critical line for ${SLCI}_{90 %} (\hat{η})$ distributions.

Distributions of ${SLCI}_{90 %} ({\hat{η}}_{M L E})$ at: (a) β_true = 2; (b) β_true = 3; and (c) β_true = 4; and ${SLCI}_{90 %} ({\hat{η}}_{M R R})$ at: (d) β_true = 2; (e) β_true = 3; and (f) β_true = 4 (test duration: 120% of η_true).

In fact, the distributions of Weibull estimators were not normal in most simulation conditions. Therefore, the upper and lower bound of the confidence intervals (e.g., SE_5% and SE_95%, respectively) must be represented. We provide these data in the Supplementary Materials.

4.2. Fixed Censoring Interval

We fixed the censoring interval at 20% of η_true, the baseline case for the censoring interval, to examine the effects of both the number of specimens and test duration. Figure 11 shows the convergence ratio distributions of MLE numerical estimation. The convergence ratio decreased when the number of specimens was small, and the test duration short. This tendency was enlarged when the value of β_true was increased. As previously mentioned, if the convergence ratios were too low, there would be the filtering effect. For MRR estimation, the convergence ratios were mostly close to unity in all simulation cases.

Convergence ratio distributions of MLE numerical estimation at: (a) β_true = 2; (b) β_true = 3; and (c) β_true = 4 (censoring interval: 20% of η_true).

Figure 12 shows the distributions of ${SE}_{50 %} (\hat{β})$ . For MLE, when the number of specimens was relatively small, there was likely a tendency toward overestimation (i.e., $SE (\hat{β}) > 0$ ). For MRR, overestimation was shown at short test durations and underestimation was shown at long test durations.

Distributions of ${SE}_{50 %} ({\hat{β}}_{M L E})$ at: (a) β_true = 2; (b) β_true = 3; and (c) β_true = 4 and ${SE}_{50 %} ({\hat{β}}_{M R R})$ at: (d) β_true = 2; (e) β_true = 3; and (f) β_true = 4 (censoring interval: 20% of η_true).

Figure 13 shows the distributions of ${SE}_{50 %} (\hat{η})$ . When MLE was used, very little bias was observed in all simulation ranges, as in the fixed test duration case (see Figure 8a–c). For MRR, overestimation (i.e., $SE (\hat{η}) > 0$ ) occurred when the number of specimens was relatively small, except in cases of short test duration. This tendency was amplified when β_true was relatively small.

Figure 14 shows the distributions of ${SLCI}_{90 %} (\hat{β})$ . As anticipated, there was quite large variance in $\hat{β}$ when the number of specimens was relatively small and the test duration was short. It is likely that very long test durations are not useful for reducing estimator variance. This phenomenon is natural because censoring beyond a certain time only returned repeated meaningless results (i.e., all the specimens were cracked after this time). As in the fixed test duration case (see Figure 9), critical lines are observed in the distributions of ${SLCI}_{90 %} (\hat{β})$ . . The areas after critical line region increased when the value of β_true was relatively high.

Distributions of ${SLCI}_{90 %} ({\hat{β}}_{M L E})$ at: (a) β_true = 2; (b) β_true = 3; (c) β_true = 4 and ${SLCI}_{90 %} ({\hat{β}}_{M R R})$ at: (d) β_true = 2; (e) β_true = 3; (f) β_true = 4 (censoring interval: 20% of η_true).

Figure 15 shows the distributions of ${SLCI}_{90 %} (\hat{η})$ . The overall values of the ${SLCI}_{90 %} (\hat{η})$ distributions were much lower than those of the ${SLCI}_{90 %} (\hat{β})$ distributions especially at high β_true. As in the case of ${SLCI}_{90 %} (\hat{β})$ , too long a test duration was not useful for reducing estimator variance. Contrary to the fixed test duration case (see Figure 10), there were critical lines in ${SLCI}_{90 %} (\hat{η})$ distributions.

The upper and lower bounds for this fixed censoring interval case are also represented in the Supplementary Materials.

4.3. Fixed Number of Specimen

We fixed the number of specimen at 10, the baseline case for the number of specimens, to examine both the effects of censoring interval and test duration. Figure 16 shows the convergence ratio distributions of MLE numerical estimation. It was quite complicated to find a general tendency from these results. We hypothesize this complexity is due to the complex distribution of the number of censoring times (see Figure 17). For example, if only one censoring was implemented during the simulation, the convergence ratio reaches unity even though the experimental condition of the simulation was very poor. For MRR estimation, the convergence ratios were mostly close to unity in all simulation cases.

Convergence ratio distributions of MLE numerical estimation at: (a) β_true = 2; (b) β_true = 3; and (c) β_true = 4 (number of specimens: 10).

Distribution of the number of censoring times during the test duration.

In this case, with a fixed number of specimens, the distributions of SE_50% and SLCI_90% were very complex and it was difficult to find general tendencies for both the MLE and MRR cases. Therefore, we do not represent these results in this manuscript, but in the Supplementary Materials instead.

In fact, we think that the end cracking fraction would be a more appropriate factor of estimation uncertainty than test duration. First, end cracking fraction of the test is not directly related to the number of censoring times when the censoring interval is pre-determined. Second, it does not produce repeated meaningless results after a certain time (i.e., test will end when all specimens are cracked if end cracking fraction is set to unity). We will study the effects of end cracking fraction on Weibull estimation uncertainties in later research.

5. Conclusions

The main goal of this study is to suggest proper experimental conditions for experimenters who want to develop a probabilistic SCC initiation model through cracking tests. We consider the widely used MRR and MLE methods for Weibull estimation. By using Monte Carlo simulation, MRR and MLE estimator uncertainties were quantified in various experimental conditions. The following conclusions can be drawn:

It is possible to calculate the confidence interval and bias of estimators when the real cracking test conditions are given.
Very little bias is observed in all simulation ranges when MLE is used to estimate the scale parameter η.
The overall deviations of $\hat{η}$ are much lower than those of $\hat{β}$ in the simulation study range. This effect is enlarged when the value of β_true is relatively high. Therefore, it is not recommended to estimate β from a cracking test when the experimental conditions are poor.
It is likely that there are critical lines after which estimators whose variances are too large are produced. Near the critical lines, the gradients of SLCI_90% are very high. It is recommended that experimenters avoid this region.
Before the critical line region, too narrow censoring interval, or too long test duration, is not useful for reducing the estimation uncertainty.

6. Outlook

The following issues will be considered in the later research:

In this study, it is assumed that censoring interval is time-independent variable. However, time-dependent censoring interval is more general for a real SCC test.
The end cracking fraction seems more appropriate than the test duration for use as a factor of estimation uncertainty.
To improve the convergence ratio of MLE, we will consider the numerical algorithm which restricts β > 1.
If a cost function (e.g., specimen cost and labor cost) is obtained for an experiment, it will be possible to find out an optimum experimental condition which returns minimum estimation uncertainty with a given cost.

Acknowledgments

This work was supported by the Nuclear Safety Research Program through the Korea Foundation of Nuclear Safety (KOFONS) granted financial resource from the Nuclear Safety and Security Commission (NSSC) Republic of Korea (No. 1403006). Authors are grateful to Chanseok Park of Pusan National University for helpful discussion.

Supplementary Materials

The following are available online at www.mdpi.com/1996-1944/9/7/521/s1. Derivation of interval censored ML simultaneous equation for 2-parameter Weibull distribution (word file); Raw data of the simulation results for “fixed test duration”, “fixed censoring interval”, and “fixed specimen number” cases (excel files); All contour plots of the simulation results, which contains the upper bounds (i.e., SE_95%), lower bounds (i.e., SE_5%), and the contour plots for the fixed specimen number case (pdf file).

Author Contributions

J.P.P. conceived the idea for this research, performed the simulation study, analyzed the data, and wrote the paper. C.B.B. The complete guide to suicide. supervised the research, advised the data analysis, and reviewed this manuscript.

Conflicts of Interest

The authors declare no conflict of interest.

References

1. Lunceford W., DeWees T., Scott P. EPRI Materials Degradation Matrix, Rev. 3. EPRI; Palo Alto, CA, USA: 2013. 3002000628. [Google Scholar]

2. Scott P., Meunier M.-C. Materials Reliability Program: Review of Stress Corrosion Cracking of Alloys 182 and 82 in PWR Primary Water Service (MRP-220) EPRI; Palo Alto, CA, USA: 2007. Rep. No. 1015427. [Google Scholar]

3. Kim K.J., Do E.S. Technical Report: Inspection of Bottom Mounted Instrumentation Nozzle. Korea Institute of Nuclear Safety (KINS); Daejeon, Korea: 2015. KINS/RR-1360. (In Korean) [Google Scholar]

4. Amzallag C., Hong S.L., Pages C., Gelpi A. Stress corrosion life assessment of Alloy 600 PWR components; Proceedings of the 9th International Symposium on Environmental Degradation of Materials in Nuclear Power Systems, Water Reactors 1999; Newport Beach, CA, USA. 1–5 August 1999. [Google Scholar]

5. Garud Y.S. Stress Corrosion Cracking Initiation Model for Stainless Steel and Nickel Alloys. EPRI; Palo Alto, CA, USA: 2009. 1019032. [Google Scholar]

6. Erickson M., Ammirato F., Brust B., Dedhia D., Focht E., Kirk M., Lange C., Olsen R., Scott P., Shim D., et al. Models and Inputs Selected for Use in the xLPR Pilot Study. EPRI; Palo Alto, CA, USA: 2011. 1022528. [Google Scholar]

7. Weibull W. A Statistical Theory of the Strength of Materials. Generalstabens Litografiska Anstalts Förlag; Stockholm, Sweden: 1939. [Google Scholar]

8. Eason E. Materials Reliability Program: Effects of Hydrogen, pH, Lithium and Boron on Primary Water Stress Corrosion Crack Initiation in Alloy 600 for Temperatures in the Range 320–330 °C (MRP-147) EPRI; Palo Alto, CA, USA: 2005. 1012145. [Google Scholar]

9. Hwang I.S., Kwon S.U., Kim J.H., Lee S.G. An intraspecimen method for the statistical characterization of stress corrosion crack initiation behavior. Corrosion. 2001;57:787–793. doi: 10.5006/1.3280613. [CrossRef] [Google Scholar]

10. McCool J. Using the Weibull Distribution: Reliability, Modeling, and Inference. John Wiley & Sons; Hoboken, NJ, USA: 2012. [Google Scholar]

11. Wadsworth G.P., Bryan J.G. Introduction to Probability and Random Variables. McGraw-Hill; New York, NY, USA: 1960. [Google Scholar]

12. Benard A., Bos-Levenbach E.C. The plotting of observations on probability paper. Stat. Neerl. 1953;7:163–173. doi: 10.1111/j.1467-9574.1953.tb00821.x. (In Dutch) [CrossRef] [Google Scholar]

13. ReliaSoft Corporation . Life Data Analysis Reference Book (E-Book) ReliaSoft Corporation; Tucson, AZ, USA: 2014. [Google Scholar]

14. Merkle J.G., Wallin K., McCabe D.E. Technical Basis for an ASTM Standard on Determining the Reference Temperature, T0, for Ferritic Steels in the Transition Range. USNRC; Washington, DC, USA: 1998. NUREG/CR-5504. [Google Scholar]

15. Genschel U., Meeker W.Q. A comparison of maximum likelihood and median-rank regression for Weibull estimation. Qual. Eng. 2010;22:236–255. doi: 10.1080/08982112.2010.503447. [CrossRef] [Google Scholar]

16. Ross S.M. Introduction to Probability and Statistics for Engineers and Scientists. 4th ed. Elsevier Academic Press; Atlanta, GA, USA: 2009. [Google Scholar]

17. Hong J.D., Jang C., Kim T.S. PFM application for the PWSCC integrity of Ni-base alloy welds—Development and application of PINEP-PWSCC. Nucl. Eng. Technol. 2012;44:961–970. doi: 10.5516/NET.07.2012.017. [CrossRef] [Google Scholar]

18. Dozaki K., Akutagawa D., Nagata N., Takihuchi H., Norring K. Effects of dissolved hydrogen condtent in PWR primary water on PWSCC initiation property. EJAM. 2010;2:65–76.[Google Scholar]

19. Garud Y.S. SCC initiation model and its implementation for probabilistic assessment; Proceedings of the ASME Pressure Vessels & Piping Division; Bellevue, WA, USA. 18–22 July 2010. [Google Scholar]

20. Pradhan B., Kundu D. Analysis of interval-censored data with Weibull lifetime distribution. Sankhya B. 2014;76:120–139. doi: 10.1007/s13571-013-0076-1. [CrossRef] [Google Scholar]

Articles from Materials are provided here courtesy of Multidisciplinary Digital Publishing Institute (MDPI)

Download Kaizoku Sentai Gokaiger Sub Indo Full Episode ▶

This article appears in the Life Data Analysis Reference book.

The Bayesian methods presented next are for the 2-parameter Weibull distribution. Bayesian concepts were introduced in Parameter Estimation. This model considers prior knowledge on the shape ([math]beta,![/math]) parameter of the Weibull distribution when it is chosen to be fitted to a given set of data. There are many practical applications for this model, particularly when dealing with small sample sizes and some prior knowledge for the shape parameter is available. For example, when a test is performed, there is often a good understanding about the behavior of the failure mode under investigation, primarily through historical data. At the same time, most reliability tests are performed on a limited number of samples. Under these conditions, it would be very useful to use this prior knowledge with the goal of making more accurate predictions. A common approach for such scenarios is to use the 1-parameter Weibull distribution, but this approach is too deterministic, too absolute you may say (and you would be right). The Bayesian-Weibull model in Weibull++ (which is actually a true 'WeiBayes' model, unlike the 1-parameter Weibull that is commonly referred to as such) offers an alternative to the 1-parameter Weibull, by including the variation and uncertainty that might have been observed in the past on the shape parameter. Applying Bayes's rule on the 2-parameter Weibull distribution and assuming the prior distributions of [math]beta,![/math] and [math]eta,![/math] are independent, we obtain the following posterior pdf:

[math] f(beta ,eta |Data)=dfrac{L(beta ,eta )varphi (beta )varphi (eta )}{ intnolimits_{0}^{infty }intnolimits_{0}^{infty }L(beta ,eta )varphi (beta )varphi (eta )deta dbeta } ,![/math]

In this model, [math]eta,![/math] is assumed to follow a noninformative prior distribution with the density function [math] varphi (eta )=dfrac{1}{eta } ,![/math]. This is called Jeffrey's prior, and is obtained by performing a logarithmic transformation on [math]eta,![/math]. Specifically, since [math]eta,![/math] is always positive, we can assume that ln([math]eta,![/math]) follows a uniform distribution, [math]U( - ∞, + ∞).,![/math] Applying Jeffrey's rule as given in Gelman et al. [9] which says 'in general, an approximate non-informative prior is taken proportional to the square root of Fisher's information,' yields [math] varphi (eta )=dfrac{1}{eta },![/math].

The prior distribution of [math]beta,![/math], denoted as [math] varphi (beta ),![/math], can be selected from the following distributions: normal, lognormal, exponential and uniform. The procedure of performing a Bayesian-Weibull analysis is as follows:

Collect the times-to-failure data.
Specify a prior distribution for [math]beta,![/math] (the prior for [math]eta,![/math] is assumed to be [math]1/beta,![/math]).
Obtain the posterior pdf from the above equation.

In other words, a distribution (the posterior pdf) is obtained, rather than a point estimate as in classical statistics (i.e., as in the parameter estimation methods described previously in this chapter). Therefore, if a point estimate needs to be reported, a point of the posterior pdf needs to be calculated. Typical points of the posterior distribution used are the mean (expected value) or median. In Weibull++, both options are available and can be chosen from the Analysis page, under the Results As area, as shown next.

The expected value of [math]beta,![/math] is obtained by:

[math] E(beta )=intnolimits_{0}^{infty }intnolimits_{0}^{infty }beta cdot f(beta ,eta |Data)dbeta deta ,![/math]

Similarly, the expected value of [math]eta,![/math] is obtained by:

[math] E(eta )=intnolimits_{0}^{infty }intnolimits_{0}^{infty }eta cdot f(beta ,eta |Data)dbeta deta ,![/math]

The median points are obtained by solving the following equations for [math] breve{beta} ,![/math] and [math] breve{eta} ,![/math] respectively:

[math] intnolimits_{0}^{infty }intnolimits_{0}^{breve{beta}}f(beta ,eta |Data)dbeta deta =0.5 ,![/math]

and:

[math] intnolimits_{0}^{breve{eta}}intnolimits_{0}^{infty }f(beta ,eta |Data)dbeta deta =0.5 ,![/math]

Of course, other points of the posterior distribution can be calculated as well. For example, one may want to calculate the 10th percentile of the joint posterior distribution (w.r.t. one of the parameters). The procedure for obtaining other points of the posterior distribution is similar to the one for obtaining the median values, where instead of 0.5 the percentage of interest is given. This procedure actually provides the confidence bounds on the parameters, which in the Bayesian framework are called ‘‘Credible Bounds.‘‘ However, since the engineering interpretation is the same, and to avoid confusion, we refer to them as confidence bounds in this reference and in Weibull++.

Posterior Distributions for Functions of Parameters

As explained in Parameter Estimation, in Bayesian analysis, all the functions of the parameters are distributed. In other words, a posterior distribution is obtained for functions such as reliability and failure rate, instead of point estimate as in classical statistics. Therefore, in order to obtain a point estimate for these functions, a point on the posterior distributions needs to be calculated. Again, the expected value (mean) or median value are used. It is important to note that the Median value is preferable and is the default in Weibull++. This is because the Median value always corresponds to the 50th percentile of the distribution. On the other hand, the Mean is not a fixed point on the distribution, which could cause issues, especially when comparing results across different data sets.

pdf of the Times-to-Failure

The posterior distribution of the failure time [math]t,![/math] is given by:

[math] f(T|Data)=intnolimits_{0}^{infty }intnolimits_{0}^{infty }f(T,beta ,eta )f(beta ,eta |Data)deta dbeta ,![/math]

where:

[math] f(T,beta ,eta )=dfrac{beta }{eta }left( dfrac{T}{eta }right) ^{beta -1}e^{-left( dfrac{T}{eta }right) ^{beta }} ,![/math]

For the pdf of the times-to-failure, only the expected value is calculated and reported in Weibull++.

Reliability

In order to calculate the median value of the reliability function, we first need to obtain posterior pdf of the reliability. Since [math]R(T),![/math] is a function of [math]beta,![/math], the density functions of [math]beta,![/math] and [math]R(T),![/math] have the following relationship:

[math] begin{align} f(R|Data,T)dR = & f(beta |Data)dbeta) = & (intnolimits_{0}^{infty }f(beta ,eta |Data)d{eta}) d{beta} =& dfrac{intnolimits_{0}^{infty }L(beta ,eta )varphi (beta )varphi (eta )deta }{intnolimits_{0}^{infty }intnolimits_{0}^{infty }L(beta ,eta )varphi (beta )varphi (eta )deta dbeta }dbeta end{align},![/math]

The median value of the reliability is obtained by solving the following equation w.r.t. [math] breve{R}: ,![/math]

[math] intnolimits_{0}^{breve{R}}f(R|Data,T)dR=0.5 ,![/math]

The expected value of the reliability at time [math]t,![/math] is given by:

[math] R(T|Data)=intnolimits_{0}^{infty }intnolimits_{0}^{infty }R(T,beta ,eta )f(beta ,eta |Data)deta dbeta ,![/math]

where:

[math] R(T,beta ,eta )=e^{-left( dfrac{T}{eta }right) ^{^{beta }}} ,![/math]

Failure Rate

The failure rate at time is given by:

[math] lambda (T|Data)=dfrac{intnolimits_{0}^{infty }intnolimits_{0}^{infty }lambda (T,beta ,eta )L(beta ,eta )varphi (eta )varphi (beta )deta dbeta }{intnolimits_{0}^{infty }intnolimits_{0}^{infty }L(beta ,eta )varphi (eta )varphi (beta )deta dbeta } ,![/math]

where:

[math] lambda (T,beta ,eta )=dfrac{beta }{eta }left( dfrac{T}{eta }right) ^{beta -1} ,![/math]

Bounds on Reliability for Bayesian-Weibull

The confidence bounds calculation under the Bayesian-Weibull analysis is very similar to the Bayesian Confidence Bounds method described in the previous section, with the exception that in the case of the Bayesian-Weibull Analysis the specified prior of [math]beta,![/math] is considered instead of an non-informative prior. The Bayesian one-sided upper bound estimate for [math]R(T),![/math] is given by:

[math] intnolimits_{0}^{R_{U}(T)}f(R|Data,t)dR=CL ,![/math]

Using the posterior distribution, the following is obtained:

[math] dfrac{intnolimits_{0}^{infty }intnolimits_{texp (-dfrac{ln (-ln R_{U})}{beta })}^{infty }L(beta ,eta )varphi (beta )varphi (eta )deta dbeta }{intnolimits_{0}^{infty }intnolimits_{0}^{infty }L(beta ,eta )varphi (beta )varphi (eta )deta dbeta }=CL ,![/math]

The above equation can be solved for [math]{{R}_{U}}(t),![/math]. The Bayesian one-sided lower bound estimate for [math] R(t) ,![/math] is given by:

[math] intnolimits_{0}^{R_{L}(t)}f(R|Data,t)dR=1-CL ,![/math]

Using the posterior distribution, the following is obtained:

[math] dfrac{intnolimits_{0}^{infty }intnolimits_{0}^{Texp (-dfrac{ln (-ln R_{L})}{beta })}L(beta ,eta )varphi (beta )varphi (eta )deta dbeta }{intnolimits_{0}^{infty }intnolimits_{0}^{infty }L(beta ,eta )varphi (beta )varphi (eta )deta dbeta }=1-CL ,![/math]

The above equation can be solved for [math]{{R}_{L}}(t),![/math]. The Bayesian two-sided bounds estimate for [math]R(t),![/math] is given by:

[math] intnolimits_{R_{L}(t)}^{R_{U}(t)}f(R|Data,t)dR=CL ,![/math] which is equivalent to:

[math] intnolimits_{0}^{R_{U}(t)}f(R|Data,t)dR=(1+CL)/2 ,![/math]

and:

[math] intnolimits_{0}^{R_{L}(t)}f(R|Data,T)dR=(1-CL)/2 ,![/math]

Using the same method for one-sided bounds, [math]{{R}_{U}}(t),![/math] and [math]{{R}_{L}}(t),![/math] can be computed.

Bounds on Time for Bayesian-Weibull

Following the same procedure described for bounds on Reliability, the bounds of time [math]t,![/math] can be calculated, given [math]R,![/math]. The Bayesian one-sided upper bound estimate for [math]t(R),![/math] is given by:

[math] intnolimits_{0}^{T_{U}(R)}f(T|Data,R)dT=CL ,![/math]

Using the posterior distribution, the following is obtained:

[math] dfrac{intnolimits_{0}^{infty }intnolimits_{0}^{T_{U}exp (-dfrac{ln (-ln R)}{beta })}L(beta ,eta )varphi (beta )varphi (eta )deta dbeta }{intnolimits_{0}^{infty }intnolimits_{0}^{infty }L(beta ,eta )varphi (beta )varphi (eta )deta dbeta }=CL ,![/math]

The above equation can be solved for [math]{{T}_{U}}(R),![/math]. The Bayesian one-sided lower bound estimate for [math]T(R),![/math] is given by:

[math] intnolimits_{0}^{T_{L}(R)}f(T|Data,R)dT=1-CL ,![/math]

or:

[math] dfrac{intnolimits_{0}^{infty }intnolimits_{T_{L}exp (dfrac{-ln (-ln R)}{beta })}^{infty }L(beta ,eta )varphi (beta )varphi (eta )deta dbeta }{intnolimits_{0}^{infty }intnolimits_{0}^{infty }L(beta ,eta )varphi (beta )varphi (eta )deta dbeta }=CL ,![/math]

The above equation can be solved for [math]{{T}_{L}}(R),![/math]. The Bayesian two-sided lower bounds estimate for [math]T(R),![/math] is:

[math] intnolimits_{T_{L}(R)}^{T_{U}(R)}f(T|Data,R)dT=CL ,![/math]

which is equivalent to:

[math] intnolimits_{0}^{T_{U}(R)}f(T|Data,R)dT=(1+CL)/2 ,![/math]

Reliasoft Weibull Crack Meaning

and:

[math] intnolimits_{0}^{T_{L}(R)}f(T|Data,R)dT=(1-CL)/2 ,![/math]

Reliasoft Alta

Bayesian-Weibull Example

A manufacturer has tested prototypes of a modified product. The test was terminated at 2,000 hours, with only 2 failures observed from a sample size of 18. The following table shows the data.

Number of State	State of F or S	State End Time
1	F	1180
1	F	1842
16	S	2000

Because of the lack of failure data in the prototype testing, the manufacturer decided to use information gathered from prior tests on this product to increase the confidence in the results of the prototype testing. This decision was made because failure analysis indicated that the failure mode of the two failures is the same as the one that was observed in previous tests. In other words, it is expected that the shape of the distribution (beta) hasn't changed, but hopefully the scale (eta) has, indicating longer life. The 2-parameter Weibull distribution was used to model all prior tests results. The estimated beta ([math]beta,![/math]) parameters of the prior test results are as follows:

Betas Obtained for Similar Mode
1.7
2.1
2.4
3.1
3.5

Solution

Reliasoft Prism

First, in order to fit the data to a Bayesian-Weibull model, a prior distribution for beta needs to be determined. Based on the beta values in the prior tests, the prior distribution for beta is found to be a lognormal distribution with [math]mu = 0.9064,![/math], [math]sigma = 0.3325,![/math]. (The values of the parameters can be obtained by entering the beta values into a Weibull++ standard folio and analyzing it using the lognormal distribution and the RRX analysis method.)

Next, enter the data from the prototype testing into a standard folio. On the control panel, choose the Bayesian-Weibull > B-W Lognormal Prior distribution. Click Calculate and enter the parameters of the lognormal distribution, as shown next.

Click OK. The result is Beta (Median) = 2.361219 and Eta (Median) = 5321.631912 (by default Weibull++ returns the median values of the posterior distribution). Suppose that the reliability at 3,000 hours is the metric of interest in this example. Using the QCP, the reliability is calculated to be 76.97% at 3,000 hours. The following picture depicts the posterior pdf plot of the reliability at 3,000, with the corresponding median value as well as the 10th percentile value. The 10th percentile constitutes the 90% lower 1-sided bound on the reliability at 3,000 hours, which is calculated to be 50.77%.

Reliasoft Software

The pdf of the times-to-failure data can be plotted in Weibull++, as shown next:

Reliasoft Weibull Crack Key

Retrieved from 'https://www.reliawiki.com/index.php?title=Bayesian-Weibull_Analysis&oldid=35770'

Associated Data

Abstract

1. Introduction

2. Weibull Estimation

2.1. Weibull Distribution

2.2. Median Rank Regression

Table 1

2.3. Maximum Likelihood Estimation

3. Monte Carlo Simulation

Table 2

Table 3

4. Results and Discussion

4.1. Fixed Test Duration

4.2. Fixed Censoring Interval

4.3. Fixed Number of Specimen

5. Conclusions

6. Outlook

Acknowledgments

Supplementary Materials

Author Contributions

Conflicts of Interest

References

Posterior Distributions for Functions of Parameters

Bounds on Reliability for Bayesian-Weibull

Bounds on Time for Bayesian-Weibull

Reliasoft Weibull Crack Meaning

Reliasoft Alta

Bayesian-Weibull Example

Reliasoft Prism

Reliasoft Software

Reliasoft Weibull Crack Key
